Made in Shipshewana, IN.
Heavy Duty Windmills
30 ft. Aluminum
Windmill Painted Red/White/Blue by customer in
|Bring back that
old country charm of yesterday. Beautify your
home. Add value to your property. Relax while
you watch your windmill spin with the wind and
Old Glory flying in the breeze.
Our quality built windmills feature an aluminum
structure with stainless steel bolts and nuts.
This means they will not rust and never need to
be painted like so many styles found elsewhere.
All windmills come with decal tape on the fan
blades and tail fin in 2 colors RED or GREEN w/
YELLOW pin stripes.
Again, that means no paint to chip off.
with double rainbow in Bethesda, TX painted by
These windmills will bring
back the beauty of the old farm windmills to your
yard, acreage or farm. They are designed to the
highest standards and manufactured from high quality
stainless steel and aluminum. When properly anchored,
they will withstand the high winds found in almost any
area of the country. All joints are welded or
assembled with stainless steel bolts. Special plastic
bearings are used on the fan assembly of all models as
well as the two bearing support assemblies on the 18 /
22 & 30 ft model. All models are assembled with
horizontal/vertical & diagonal supports. Fan blade
tips and tail assembly have red tape on both sides.
All required hardware includes stainless steel nuts
& bolts as well as four in-ground anchors.
Assembly can be done with a minimum of tools. No heavy
equipment required but recommend 2-3 strong men to
erect the 18-30 ft models. Best of all, these
windmills will never rust and never need painting.
On the 18, 22, & 30ft models, the fan has a
vesconite bushing that requires no lubrication.
***Ladder not included***
Aluminum fan & tail
assemblies available for replacing existing
equipment, call or email for more information.
As shown by
weight there are significant differences between
the 6-12ft and the 18-30ft. The 6-12ft are
considered garden windmills whereas the 18-30ft
would be considered full sized or "real"
windmills. The 6-12ft windmills use 3/4"
tubing with the fan rotating on a 1/2" shaft
with bearings that require annual greasing.
Shipped by UPS. The 18-30ft models are
made with 1" tubing with larger bolts and deeper
& wider anchors. Vestconite bushings are
used on the fan that do not require lubrication.
Fan blades are supported with an aluminum hoop
and the vertical shaft is supported by two
bearings. Shipping costs for the 18-30ft models
range from $200.00- $295.00 depending on size
|All models assembled with
horizontal/vertical & diagonal
|Twin-bearing supports for
fan/tail assembly on 18, 22
& 30ft models.
|One-inch stainless steel rod supports
the fan & tail. Square tubing is
1" square aluminum.
Windmill Pond Aerators
| 20 ft w/
60” fan $1,595.00*
| 30 ft w/60”
100 ft of Polyethelene air line and one
*Capacity – (approx) 2 cu. ft. per min @
*Start-up (approx) 3 mph wind
| Back to top
Duty Aluminum Windmills made in Iowa
Heavy duty windmills
are measured from ground to center of fan.
For more information call (641)562-2198
Or (866)561-2198 Toll Free
no longer available!*****
- 15 ft tower with 48" aluminum
- 15 ft tower with 60" aluminum
- 20 ft tower with 48" aluminum
- 20 ft tower with 60" aluminum
ft tower with 60" aluminum
ft tower with 72" aluminum
- 30 ft tower with 72" aluminum
- 35 ft tower with 72" aluminum
ft tower with 92" aluminum
- 40 ft tower with 92" aluminum
- Wheel and fantail with baked on power
- Tapered roller bearings and seals on
tail and fan assembly.
- Plated bolts, nuts, washers & screws
- Assembly required
- Decal tape on fan tips and tail
Replacement Head Kits:
system for 15' and
20' add $629
(2 piston air compressor)
Two hinged foot
pads 15' & 20'
w/standing windmill up)
Two hinged foot
pads 30' & 40' tower
$75 (assists w/standing
New December 2019
custom design your windmill by powder
coating the tower with colors of your
We can wrap the tail in various designs
and can add a company, family or sports
team name to the fan.
Example is a red, white, and blue
15' tower with wrapped tail.
Windmills that generate electricity!
Note: All windmills measured from
ground to center of fan. FOB:
Note: Fan rotates on 5 bolt
machined 3,500# capacity hub w/ 1 1/8" tapered
Note: These windmills
have the appearance and structure of the
Bolt pattern: 15ft--39
1/4"sq. 20ft--51" sq.
25ft--67" sq 30ft--75"
40ft--99 1/2" sq
Warranty: Fan = 10 years of
3,500lb rated hub w/tapered bearings = 10 years
Aeration system: bearings & cam shaft
= 5 years
Aeration system: Goodyear airbag = 10
Call 641-562-2198 for actual shipping
Extra charge for
delivery to residential address
For more information
Back to top
